Pipes and Tubes
SPAR produce now a high quality laser welded tubes from 0.19 mm to 152.4 mm diameter, and various other sizes of Round Tubes, Square Tubes, Rectangular Tubes that can be used for any application requiring the greatest performance,
Scaffolding tubes are supplied in HR (Black) & Galvanized type, mainly 3.2mm and 4.0mm thickness with standard specification EN 39, EN 10219, BS1139
| Strip Width | Tube | Nominal Value (Type 4) | Nominal Value (Type 3) | Tolerances |
|---|---|---|---|---|
| Wall thickness | 4 | 3.2 | -10% | 61 |
| Outside diameter(mm) | 48.3 | 48.3 | ± 0.5 mm | 61 |
| Inside diameter, (mm) | 40.3 | 41.9 | 61 | |
| Mass (Kg/m) | 4.37 | 3.56 | -7.50% | 61 |
Round Tubes are supplied in HR (Black), Galvanized (Hot-Dip) or Pre-galvanized types Can be use in structural and fencing application, Produced from ½' to 6" inch different thickness.
Square Tubes are supplied only in HR (Black) & Pre-Galvanized type. Can be used in structural, Furniture and other commercial application. Produced with various other sizes and thicknesses, from 16mm x 16mm to 120mm x 120mm
Rectangular Tubes are supplied only in HR (Black) & Pre-Galvanized type. Can be used in structural, Furniture and other commercial application Produced with different sizes and thicknesses from 20mm x 15mm to 100mm x 60mm
Have a production challenge? We have offices in Saudi Arabia (Al- Jubail, Riyadh), UK, DUBAI - UAE and RAK - UAE. Our extensive range of products gives us the ability to offer the best solution to suit your projects.
